Machine Trades Print Reading, 7th Edition

Machine Trades Print Reading is a combination text and write-in workbook designed to help students develop the skills required to visualize and interpret industrial prints. Ideal for beginner students, this text provides very basic explanations supported by numerous print reading activities. The new edition complies with the most recent ASME Y14.5-2018 standard, resulting in a heavy revision of Unit 15—Geometric Dimensioning and Tolerancing. In addition to an overview of the role of prints in the design and manufacturing process, this text teaches students the fundamentals of visualizing shapes, line usage, title blocks and notes, math, measurement, dimensions, and tolerances. Print reading activities are included at the end of most units to provide students with valuable hands-on learning opportunities.

• The concise topical format provides students with accessible content for easy comprehension.
• Authentic drawings and an abundance of activities allow for real-world, applied learning for a diverse class.
• Improved pedagogical learning tools help students learn, retain, apply, and think critically.
