Residential Roof Assemblies Quick-Card based on the 2024 IRC PRE-ORDER

Special Price $9.85 Regular Price $10.95

In stock

Product Code

9781622705900

This six-page, full-color card quickly covers roofing information used in architectural plans and engineering drawings. Includes several quick lookup tables and pictures based on the new 2024 International Residential Code (IRC).

Features:

WEATHER & FIRE PROTECTION
- Roof Assemblies (R902.1)
- Building-Integrated Photovoltaic (BIPV) Systems (R902.3)
- Rooftop-Mounted PV Panel Systems (R902.4)
- Weather Protection (R903.1)
- Materials (R904)
- Roof Covering Application (R905.1)
FLASHING & DRAINAGE
- Flashing (R903.2)
- Roof Drainage (R903.4)
- Coping (R903.3)
- Ice Barriers (R905.1.2)
UNDERLAYMENT
- Underlayment Table (Based on Table R905.1.1(2))
- Underlayment Systems Table (Based on Table R905.1.1(3))
- Underlayment (R905.1.1)
CONCRETE & CLAY TILE
- Sheathing Requirements (R905.3.1)
- Slope (R905.3.2)
- Clay & Concrete Tile (R905.3.4 & R905.3.5)
- Wind Resistance of Concrete & Clay Tile (R905.3.6)
- Fasteners (R905.3.7)
- Application (R905.3.8)
- Flashing (905.3.9)
ASPHALT SHINGLES
- Asphalt Shingles (R905.2)
- Asphalt Shingle Fasteners (R905.2.5, R905.2.6)
- Asphalt Shingle Flashings (R905.2.8)
- Valley Lining Material Table (Based on Table R905.2.8.2)
- Valleys (R905.2.8.2)
- Sidewall Flashing (R905.2.8.3)
- Other Flashing (R905.2.8.4)
- Drip Edge (R905.2.8.5)
SLATE SHINGLES
- Slate Shingles (R905.6)
- Classification Of Slate Shingles Tested in Accordance with ASTM D3161 (Based On Table R905.6.5)
- Slate Shingle Flashing (R905.6.7)
METAL ROOFS
- Metal Shingles (R905.4)
- Metal Roof Panels (R905.10)
- Attachment (R905.10.4)
- Wind Resistance of Metal Roof Panels (R905.10.5)
OTHER ROOFING SYSTEMS
- Mineral-Surfaced Roll Roofing (R905.5)
- Modified Bitumen Roofing (R905.11)
- Single-Ply Roofing (R905.12)
- Sprayed Polyurethane Foam Roofing (TPO) (R905.13)
- Liquid-Applied Roofing (R905.14)
BUILDING-INTEGRATED PHOTOVOLTAIC (BIPV) ROOF SYSTEMS
- BIPV Roofing Systems (R905.15)
- BIPV Roof Panels Applied Directly to The Roof Deck (R905.16)
- BIPV Shingle Solar Tiles (R905.15)
- BIPV Solar Panels (R905.16)
- BIPV Underlayment Application (Table R905.1.1(2))
- Rooftop-Mounted Photovoltaic Systems (R329.4)
- Building-Integrated Photovoltaic Systems (R329.5)
BUILT-UP ROOFS (BUR)
- Built-Up Roofs (BUR) (R905.9)
- Roof Insulation (R906)
- Reroofing (R908.1)
- Structural & Construction Loads (R908.2)
- Roof Recover (R908.4)
- Roof Recovering Over Wood Shingles or Shakes (R908.4.1)
